D C WELDING

Model

GE-W 5500 D

Maximum Output (Duty Cycle 60%)

160 Amps.

Working Voltage

20v to 30v

Open Circuit Voltage

60 Volt (Maximum)

Current Regulation Amps

40-160 Amps.

Rectifying Mode

SCR, Phase Controlled 3-phase, Rectifying Bridge

Maximum Electrode diameter

2.6 mm to 3.17 mm

AC GENERATOR

Type

Brush less with Rear Earth Magnet Rotor.

AC. Voltage On Eco Mode

N/A

AC. Voltage On Power Mode (No Load)

250 Volts (No Load) + 10 Volts, Single Phase

Rated Current

7.5 Amps.

NFB

7.5 Amps.

Rated Power

1800 VA

Peak Power

2000 VA

Frequency

58 to 60 Hz

Class of Insulation

F

ENGINE

Model

TP170FA

Type

4-Stroke, OHV, Single Cylinder, direct Injection, Swirl Chamber, Inclined type

Maximum Power

Bore x Stroke

70x60 mm

Displacement

231 cc

Starting System

Recoil / Self Start

Ignition System

N/A

Fuel

Standard Diesel

Fuel Tank Capacity

20.5 Liters

Fuel Consumption # Ltr./Hr.

0.65 Ltr./hr.

Continuous Operating Hour

12 hr.

Lube. Oil Capacity

800 ml.

Lubricating Oil Consumption

3.2 gm./Hr.

Standard Accessories

AC Plug

1 Pcs.

Tool Kit

1 Set

Welder Holder

1 Set

Earthing Clamp with Cable

1 Set

Oil Funnel

1 No.

Owners Manual

1 No.

Battery Terminal

1 Set

Battery Tray & Holding Set

1 Set

Optional

Accessories

Sheet Metal Welding Attachment (Helps to adjust low current upto 50 Amps.)

1 Kit (Additional Cost)

Costar Wheels

Optional (Wheels & Handle Sets) @ (Additional Cost)

Panel & Other Standard Features

A.C. Circuit Protector

Yes

Engine Oil Protection

No

Low Fuel Protection

No

A.C. Pilot Lamp

Yes

Fuel Level Gauge

No

A.C. Output Sockets

1 No.

Packing

Dimension LxWxH (mm)

750x550x675 mm

Dry Weight (Kgs.)

60 Kgs.

Above Specifications are for reference only, Because of continuous improvements and up-gradation by our R&D team. This specifications can change without any prior intimation
