Portable Welding Generator 175 Amp

Portable Welding Generator 175 Amp

40000 INR/Unit

Product Details:

  • Product Type Portable Welding Generator
  • Rated Voltage 240 Volt (V)
  • Starting Type Electric Start
  • Rated Frequency 50 Hertz (HZ)
  • Weight 40-60 Kilograms (kg)
  • Supply Ability : 500 Unit Per Month
  • Click to view more
X

Price And Quantity

  • 1 Unit
  • 40000 INR/Unit

Product Specifications

  • 240 Volt (V)
  • 50 Hertz (HZ)
  • 40-60 Kilograms (kg)
  • Electric Start
  • Portable Welding Generator

Trade Information

  • Cheque, Telegraphic Transfer (T/T), Cash in Advance (CID), Cash Advance (CA)
  • 500 Unit Per Month
  • 2 Days
  • No
  • Carton Boxes
  • All India
  • CPCB 2 From ICAT

Product Description

Model HPW 175 D
Applications :  Suitable for General Purpose Structural Welding, Light and medium
Maximum Output (Duty Cycle 60%)  : 160 Amps.
Working Voltage : 20v to 30 v
Open Circuit Voltage : 50 Volt (Maximum)
Current Regulation Amps : 75 Amps to 160 Amps
Rectifying Mode 3 phase - Bridge Rectifier
Maximum Electrode diameter : 2.5 mm to 4 mm


ENGINE
Model HM170 P
Type Single Cylinder Air-cooled; 4-stroke, OHV 25Ëš Inclined
Maximum Power : 6.5 HP
Bore x Stroke : 70 x 54
Displacement : 208 cc
Starting System : Recoil Start
Ignition System TCI (Transistor Control Ignition)
Fuel Standard Petrol
Fuel Tank Capacity : 3.6 Ltr.
Fuel Consumption  : 0.5 Ltr./ Hr
Continuous Operating Hour : 3.5 Hrs
Lube. Oil Capacity : 600 ml.
Lubricating Oil Consumption : 2.5 gm./Hr.

Standard Accessories
Tool Kit 1 Set
Welder Holder 1 Set
Earthing Clamp with Cable 1 Set
Oil Funnel 1 No.
Owner’s Manual 1 No.
Panel & Packing
Power Indicator Yes
Ampere Meter Yes
Engine Oil Protection Electronic Oil Alert & Indicator
Dimension LxWxH (mm) 450 x 385 x 405 Mm
Dry Weight (Kgs.) 27 Kgs.


M/S HIMALAYAN POWER MACHINES MFG CO
